Technical Specifications
- kVA Rating: 82.5 kVA
- Engine Model: Eicher E683
- No. of Cylinders: 6
- Aspiration: TCI
- Catacity (Ltr): 4.9
- Mechanical Power Output (HP): 105
- Bore x Stroke (mm): 100 x 105
- FIP Make: Bosch Inline
- Governer Make Type: Bosch Mechanical
- Lube Oil Sump Capacity (Ltr): 16
- Recommended Lube Oil: 15W40-C14
- Recommended Lube Oil Change Interval (Hrs): 500
- Genset Power Rating (KW): 66
- Alternator Model: Stamford Three Phase
- Voltage/ Frequency: 415/50
- Control Panel Model: Automatic/ Manual Panel with DSE controller 4520
- Battery Capacity: 120 AH
- 75 dBA Model
- Fuel Tank Capacity: 130 ltrs
- Dimensions (l x w x h) (mm): 3100 x 1100 x 1575
- Weight (Kg): 1600
- Fuel Consumption/ Per Hr @ 50%/75%/100% Load: 5/8/11 Ltrs
Technical Specifications are subject to change without prior notice due to continous product development
Salient Features
Low Operating Cost
- Remarkable fuel economy
- Inline fuel pump having low maintenance cost/ease of maintenance
- Economical spare parts pricing
- Higher service/oil change interval of 500-700 hrs.
- Low lube oil consumption - less than 0.1% of the fuel
High Reliability
- Volvo Group processes and technology
- Robust design: for tough segments like rental & construction.
- Inbuilt Oil Cooler: suitable for continuous operations
- High engine protections: lube oil pressure sensor, low lube pressure switch, coolant temp sensor, high temp. switch & air cleaner choke switch
- Piston cooling jets, Inbuilt oil cooler, better metallurgy: ensures longer maintenance period & overhauling period
Best Performance
- Excellent block loading capacity
- Low deration at high ambient temperature and high altitude
- Extremely low vibration and noise
- 12V electrical system
- Starter motor with thermal cut- off
Service Efficiency
- Class leading warranty on engine
- Easy serviceability
- Easy spares availability
- No special tools required
- Commonality of spare parts with trucks and buses
Application
- Corporate
- Government Projects
- Crushers
